Gearless Traction Machine-image

Gearless Traction Machine

1. GSD-SM

  • Input voltage : ac380v, 50hz
  • insulation class : f standard
  • protection grade : ip42(totally-enclosed selfcooling type)
  • Lubrication : Grease
  • Work Duty : S5-50% ED
  • Weight : 193kg
  • Max. overload torques : 200% rated torques
  • Rated Load : 320-630kg
  • Rated speed : 0.5-1.75m/s
  • Shaft Load : 2000kg
    Brake : Drum brake
    Type : MPB-70
    Braking torque : 688 Nm
    Operating voltage : DC 110V
    Holding voltage : DC 55V
    Encoder : ERN 1387

2.GSD-SM

  • Speed : 1.0 M/S
  • LOAD : 550 KG.
  • Motor Speed : 120 R/min.
  • Rated Power KW : 3.7
  • Voltage : 300V
  • Rated Current : 9.8A
  • Poles Pairs : 16P
  • Freq. HZ : 32
  • Dia MM : 320
  • Roping : 2.1

3. GSD-SM

  • Speed : 1.0 M/S
  • LOAD : 630 KG.
  • Motor Speed : 120 R/min.
  • Rated Power KW : 4.2
  • Voltage : 300V
    Rated Current : 11.2A
  • Poles Pairs : 16P
  • Freq. HZ : 32
  • Dia MM : 320
  • Roping : 2.1

Additional Information:

  • Item Code: GSD-SM
